4CH truck wireless rear view system digital wireless vehicle backup surround view camera system with monitor


Product Detail

Product Tags

4CH truck wireless rear view system digital wireless vehic

Application

The 7 Inch HD Quad-view Wireless Monitoring System is a state-of-the-art technology that provides drivers with a convenient and safe way to monitor their vehicles while on the road. One of the key benefits of this system is that it is incredibly easy to install. This means that drivers can quickly and easily set up the system and start using it to monitor their vehicles. The system supports quad view and auto pairing, which makes it ideal for a wide range of vehicles, including trucks, trailers, RVs, and more. This feature allows drivers to view up to four different camera feeds on a single screen, making it easier to monitor different areas of their vehicle at once. When paired with an HD digital wireless rear view camera, the 7 Inch HD Quad-view Wireless Monitoring System forms an excellent Wireless Vehicle Monitor System. This system provides drivers with a crystal-clear view of their surroundings, which can help to prevent accidents and increase safety on the road. In addition to its quad-view and auto pairing capabilities, the 7 Inch HD Quad-view Wireless Monitoring System also comes equipped with a range of other features. These include a high-resolution display, a user-friendly interface, and a durable construction that can withstand the rigors of daily use. Overall, the 7 Inch HD Quad-view Wireless Monitoring System is an excellent choice for any driver who wants to improve their visibility and safety on the road. With its easy installation, quad-view and auto pairing capabilities, and excellent wireless vehicle monitor system, this system is sure to meet the needs of even the most demanding drivers.

Product Details

7inch IPS screen 1024*600 monitor, up to 4 cameras display simultaneously
Built in video loop recording, support max. 256GB SD card
Strong magnetic base for easy and quick mounting anywhere, no drilling required
9600mAh large capacity type-C port rechargeable battery, battery life will last for 18h
200m (656ft) long and stable transmission distance in an open area
Infrared LEDs for clear view in low light or dark conditions
IP67 waterproof rating for working well in rainy days

Product Display

Product Parameter

Product Type

1080p 4CH truck wireless rear view system digital wireless vehicle backup surround view camera system with monitor

Specification of 7 inch TFT Wireless Monitor

Model

TF78

Screen Size

7 inch 16:9

Resolution

1024*3(RGB)*600

Contrast

800:1

Brightness

400 cd/m2

View Angle

U/D: 85, R/L: 85

Channel

2 channels

Receiving Sensitivity

21dbm

Video Compression

H.264

Latency

200ms

Transmitting Distance

200ft line of sight

Micro SD/TF CARD

Max. 128 GB (optional)

Video Format

AVI

Power Supply

DC12-32V

Power Consumption

Max.6w

Wireless Reverse Camera

Model

MRV12

Effective Pixels

1280*720 pixels

Frame Rate

25fps/30fps

Video Format

H.264

View Angle

100degree

Night Vision Distance

5-10m
